Background
This element is a basic Background. Its default form is a black rectangle.
This element must be used with HMI context.
Icon
HMI Representation
External parameters
Show/Hide all parameters
| parameter | editable via "Parameter" tab | updatable via a mapping | description | unit | type |
|---|---|---|---|---|---|
| Size on X-axis | ✔️ | ✔️ | Size of the element on the X-axis. | px | Integer number |
| Size on Y-axis | ✔️ | ✔️ | Size of the element on the Y-axis. | px | Integer number |
| X-axis position | ✔️ | ✔️ | Position of the element's upleft corner on the X-axis. | px | Integer number |
| Y-axis position | ✔️ | ✔️ | Position of the element's upleft corner on the Y-axis. | px | Integer number |
| Color | ✔️ | ✔️ | Color of the element. This parameter can be edited. | - | Hexadecimal |
| Style | ✔️ | ✔️ | CSS style of the element. You can change here parameters of the elements that are not already present in other fields. Choose a preset definition. | - | CSS |
| Blinking status | ✔️ | ✔️ | Turn it ON to make the element blink. | - | Enumeration (ON, OFF) |
| Blinking frequency | ✔️ | ✔️ | Value of the blinking frequency. You can change it to make it slower or faster blink. | hertz | Decimal number |
| Visibility | ✔️ | ✔️ | This parameter allows you to choose if you want the element to be visible or not on the scene during the execution of the scenario. If the item is part of a group, it can inherit the value of that group. | - | Enumeration (visible, hidden, inherit) |
| Angle | ✔️ | ✔️ | Angle of rotation of the element compared to its initial position. | degree | Decimal number |
Triggered behaviours
See Triggered behaviours and events page for more explanation: Triggered behaviours and events.
Show/Hide all triggered behaviours
Destroy
At the reception of the flow, the element is destroy.
No parameters for this triggered behaviour.
Events
See Triggered behaviours and events page for more explanation: Triggered behaviours and events.
Show/Hide all events
| event | description |
|---|---|
| On Parameter Value Changed | The element can send information to the model when the value of the selected parameter has changed |
| At initialization | The background can send information to the model once at initialization |
| Continually | The background can send information to the model continuously |
