House

This element is a basic house. The graphic origin of the House corresponds to the geometric center of the House.


Is an equipment	❌
Can have equipment	❌

This element must be used with 2D scene context.

Icon

Show/Hide all parameters

parameter	editable via "Parameter" tab	updatable via a mapping	description	unit	type
X-axis position	✔️	❌	Position of the element on the X-axis.	meter	Decimal number
Y-axis position	✔️	❌	Position of the element on the Y-axis.	meter	Decimal number
Z-axis position	✔️	❌	Position of the element on the Z-axis.	meter	Decimal number
Z-axis angle	✔️	❌	Angle of rotation of the element compared to its initial position.	degree	Decimal number
Threshold zoom out	✔️	❌	Zoom level from which its representation on the scene is no longer modified.	%	Decimal number
Length	❌	❌	Length of the house.	meter	Decimal number
Width	❌	❌	Width of the house.	meter	Decimal number
Height	❌	❌	Height of the house.	meter	Decimal number
longitude coordinate	❌	❌	Automatically calculated longitude value, based on the origin defined for the context and the position of the element.	degree	Decimal number
latitude coordinate	❌	❌	Automatically calculated latitude value, based on the origin defined for the context and the position of the element.	degree	Decimal number

See Triggered behaviours and events page for more explanation: Triggered behaviours and events.

Show/Hide all triggered behaviours

At the reception of the flow, the element is destroy.

No parameters for this triggered behaviour.

See Triggered behaviours and events page for more explanation: Triggered behaviours and events.

Show/Hide all events

event	description
On Parameter Value Changed	The element can send information to the model when the value of the selected parameter has changed
At initialization	The house can send information to the model once at initialization
Continually	The house can send information to the model continuously
